6018-ZZC3 Metal Shielded Ball Bearing

This precision metric ball bearing features C3 internal clearance and dual metal shields, manufactured from chrome steel SAE-52100 with pre-lubricated Chevron SRI-2 grease for immediate use in demanding industrial environments.

Superior Load Capacity

Engineered to handle substantial loads with a dynamic load rating of 13,039 lbf and static load rating of 11,128 lbf, making it ideal for heavy-duty industrial machinery and equipment.

Reliable Protection System

Double metal shields prevent contamination while retaining lubricant, ensuring longer bearing life and reduced maintenance needs in challenging operating conditions.

Versatile Performance Design

C3 internal clearance allows for thermal expansion during operation, while the precision design supports speeds up to 4,700 RPM, suitable for various industrial applications from milling machines to agricultural equipment.

Parameters

Details

01 SKU

6018-ZZC3-ITJ

02 Inner Diameter

90mm

03 Outer Diameter

140mm

04 Width

24mm

05 Material

Chrome Steel SAE-52100

06 Lubrication

Chevron SRI-2 Grease

07 Closure Type

Metal Shielded (both sides)

08 Dynamic Load

13,039 lbf

09 Static Load

11,128 lbf

10 Speed Limit

4,700 RPM

11 Compatible Part Numbers

6018ZC3, 6018 2ZC3, 118SS, 6018ZZCM, 6018.2ZJ1C3, 118KSFF, 9118DD, 773L18
