6009TBR12P4 Super Precision ABEC7 Ball Bearing

This chrome steel ball bearing delivers high precision performance with special radial clearance and light oil lubrication, designed for high-speed industrial applications requiring accuracy and reliable load handling.

6009tbr12p4 super precision abec7 ball bearing 2

6009tbr12p4 super precision abec7 ball bearing 3

Premium Manufacturing Quality

Made from SAE-52100 chrome steel with P4 class tolerance rating, this bearing provides superior accuracy and durability. The open design and light oil pre-lubrication allow for immediate use while maintaining optimal performance in demanding conditions.

Versatile Industrial Applications

Specifically engineered for high-speed operations in CNC machines, electric motors, spindles, and precision equipment. The bearing handles both radial and axial loads effectively, making it suitable for various industrial machinery and manufacturing processes.

Enhanced Performance Specifications

Features special radial clearance for thermal expansion and operates efficiently at speeds up to 16,000 RPM. The bearing supports dynamic loads of 4,700 lbf and static loads of 3,400 lbf, ensuring reliable performance in demanding applications.

Parameters

Details

01 SKU

6009-TB-P4A2H-IBC

02 Inner Diameter

45mm

03 Outer Diameter

75mm

04 Width

16mm

05 Material

Chrome Steel SAE-52100

06 Lubrication

Light Oil

07 Static Load Rating

3,400 lbf

08 Dynamic Load Rating

4,700 lbf

09 Maximum Speed

16,000 RPM

10 Precision Class

P4/ABEC7

11 Alternative Part Numbers

R109KEA7, R109SSKEA7
